Neodymium Disc Magnet - 6mm x 2mm | Gold Coating

Product code: 20076A

$1.17for 1 to 99 items
$0.95buy 100 to 999 itemsand save 18%
$0.78buy 1000+ itemsand save 33%

Prices are GST Incl.

Volume pricing available on request

Neodymium Disc Magnet - 6mm x 2mm | Gold Coating

Product Code 20076A
Pull Force* .540kg
Weight 1 gm
Style Rare Earth Disc magnet Gold
Gauss 3495
Grade N38
Coating Gold
Direction of Magnetisation Axially magnetised
Dimensions Height:2mm, Diameter:6mm
*Measured against up to 10mm mild steel.
Neodymium Disc Magnet - 6mm x 2mm | Gold Coating

Magnetic Product Description:

This rare earth disc has a diameter of 6mm and a height of 2mm. It has a magnetic flux reading of 3495 Gauss and a pull force of 540 grams. It is identified by the AMF magnet part number 20076A.


Uses for our rare earth disc magnets:

This gold-coated Neodymium disc magnet is popular with craftspeople for use in a variety of creative applications. The gold coating provides additional cosmetic benefit for projects that require an aesthetically sympathetic solution. Jewellery Makers, Artists and Craftspeople often prefer the appearance of the gold coating over the standard Nickel plating. Gold plating also provides a range of functional benefits due to Gold’s unique properties including corrosion-resistance; suitable for use in humid and environments with elevated ambient salt levels. Manufacturers of mechanical products utilise these magnets as the gold plating is an effective thermal and electrical conductor.

Neodymium Disc Magnet - 6mm x 2mm | Gold Coating (20076A)

Grade
N38 N/A
Max Operating Temperature °C
<=80 N/A
Remanence Br(T)
1.23-1.3 N/A
Remanence Br(kGs)
12.3-13 N/A
Coercivity bHc(kA/m)
>=859 N/A
Coercivity bHc(Oe)
>=10.8 N/A
Intrinsic Coercivity iHc(kA/m)
>=955 N/A
Intrinsic Coercivity iHc(Oe)
>=12 N/A
Max Energy Product(BH)max(KJ/m)
286-318 N/A
Max Energy Product(BH)max(MGOe)
36-40 N/A
Grade N38 N/A
Max Operating Temperature °C <=80 N/A
Remanence Br(T) 1.23-1.3 N/A
Remanence Br(kGs) 12.3-13 N/A
Coercivity bHc(kA/m) >=859 N/A
Coercivity bHc(Oe) >=10.8 N/A
Intrinsic Coercivity iHc(kA/m) >=955 N/A
Intrinsic Coercivity iHc(Oe) >=12 N/A
Max Energy Product(BH)max(KJ/m) 286-318 N/A
Max Energy Product(BH)max(MGOe) 36-40 N/A

NB: Ranges are indicative for product category, please check individual products for specic values within that range.

The most common coating for Neodymium magnets is Nickel + Copper + Nickel (Ni + Cu + Ni). This coating offers the magnet relatively good protection from corrosion and passive applications. If the magnet will be exposed to moisture or liquid then consider the use of an organic coating such as Epoxy. A hard wearing coating, Epoxy is suited to applications where the magnet will come under some friction or knocking.

Magnets are readily available in Blocks, Discs, Cylinders & Rings. AMF Magnetics specializes in the supply of short-run prototype magnets including Arc Segments, various magnetic orientations etc. If you need a magnet size that we don't carry in stock, submit a Design-a-Magnet enquiry for a quote on your custom magnet design.

Neodymium magnets are offered in several different grades. The first section N30-54 has an operating temperature of up to 80 degrees. Most of our stock only goes up to N38. The second section, denoted with the "M" prefix after the grade has an operating temperature 100 degrees. After this the grades are "H", "SH", "UH" & "EH". In order for the magnet to withstand a higher operating temperature, during production more of the raw material PrNd is incorporated as these elements have a naturally occurring resistance to high temperatures.
