Product code: AMFYPC10
This rare earth male threaded pot magnet has a diameter of 10mm, a total height of 12mm and a magnet housing thickness of 5mm. It has a M3 thread with an external boss of 7mm. This male threaded magnet has a pull force of 2.2kg and a weight of 3 grams. It is identified by the AMF magnet part number AMFYPC10.
This Holding Pot magnet has a strong Neodymium magnet in a mild steel cap with a protruding male boss. The steel cap serves to protect the inner magnet from damage whilst also enhancing the magnetic field through the working face of the magnet. The field curves around the inside of the cap and is projected from the active face of the magnet whilst reducing the field on the reverse side. This creates an effectively single-sided magnet that is highly desirable in some applications. The male thread can be easily attached to a non-ferrous material using a nut and washer to secure the magnet in position. Likewise, the magnet can be integrated into a larger mechanical apparatus with a female threaded receptacle.
| ModelNo. | DØ | M | H | h | Holding force(kg) | Weight (g) |
| AMFYPC10 | 10 | 3 | 12 | 5 | 2.2 | 3.5 |
| AMFYPC12 | 12 | 3 | 13 | 5 | 3.2 | 5 |
| AMFYPC16 | 16 | 4 | 13 | 5 | 5.5 | 7.5 |
| AMFYPC20 | 20 | 4 | 15 | 7 | 9 | 16 |
| AMFYPC25 | 25 | 5 | 17 | 8 | 22 | 30 |
| AMFYPC32 | 32 | 6 | 18 | 8 | 34 | 45 |
| AMFYPC36 | 36 | 6 | 18 | 8 | 41 | 57 |
| AMFYPC42 | 42 | 6 & 8 | 20 | 9 | 68 | 84 |
| AMFYPC48 | 48 | 8 | 21.5/24 | 11.5 | 81 | 130 |
| AMFYPC60 | 60 | 8 | 30 | 15 | 113 | 254 |
| AMFYPC75 | 75 | 10 | 34 | 15 | 164 | 550 |
Male Thread Neodymium Pot Magnet - Diameter 10mm x 12mm (AMFYPC10)
| Grade | |
|---|---|
| N35 | N/A |
| Max Operating Temperature °C | |
| <=80 | N/A |
| Remanence | |
| 1.18-1.25 | N/A |
| Coercivity | |
| 11.8-12.5>=859 | N/A |
| Intrinsic Coercivity | |
| >=10.8 | N/A |
| Max Energy Product | |
| >=955 | N/A |
| Grade | N35 | N/A |
| Max Operating Temperature °C | <=80 | N/A |
| Remanence | 1.18-1.25 | N/A |
| Coercivity | 11.8-12.5>=859 | N/A |
| Intrinsic Coercivity | >=10.8 | N/A |
| Max Energy Product | >=955 | N/A |
