Product code: 20007C
This rare earth disc has a diameter of 25mm and a height of 1.5mm. It has a magnetic flux reading of 751 Gauss and a pull force of 2.3kg. It is identified by the AMF magnet part number 20007C.
In the automotive industry, signage, pricing and branding communicate with potential buyers, while the vehicles themselves actually speak to the occupants of the cars in their preferred language.
Some of these vehicles are positively bossy with their so-called drivers with ever more instant demands for action. Talk about back seat drivers! These 25mmx1.5mm magnets help make this dialogue possible with their deployment throughout the vehicles construction. From simple discreet fastening systems like holding carpet securely in place, engagement in modern vehicles sophisticated electronics systems and computer software, these tiny magnets are here, there and everywhere. Just do it!
Neodymium Disc Magnet - 25mm x 1.5mm (20007C)
| Grade | |
|---|---|
| N38 | N/A |
| Max Operating Temperature °C | |
| <=80 | N/A |
| Remanence Br(T) | |
| 1.23-1.3 | N/A |
| Remanence Br(kGs) | |
| 12.3-13 | N/A |
| Coercivity bHc(kA/m) | |
| >=859 | N/A |
| Coercivity bHc(Oe) | |
| >=10.8 | N/A |
| Intrinsic Coercivity iHc(kA/m) | |
| >=955 | N/A |
| Intrinsic Coercivity iHc(Oe) | |
| >=12 | N/A |
| Max Energy Product(BH)max(KJ/m) | |
| 286-318 | N/A |
| Max Energy Product(BH)max(MGOe) | |
| 36-40 | N/A |
| Grade | N38 | N/A |
| Max Operating Temperature °C | <=80 | N/A |
| Remanence Br(T) | 1.23-1.3 | N/A |
| Remanence Br(kGs) | 12.3-13 | N/A |
| Coercivity bHc(kA/m) | >=859 | N/A |
| Coercivity bHc(Oe) | >=10.8 | N/A |
| Intrinsic Coercivity iHc(kA/m) | >=955 | N/A |
| Intrinsic Coercivity iHc(Oe) | >=12 | N/A |
| Max Energy Product(BH)max(KJ/m) | 286-318 | N/A |
| Max Energy Product(BH)max(MGOe) | 36-40 | N/A |
NB: Ranges are indicative for product category, please check individual products for specic values within that range.
The most common coating for Neodymium magnets is Nickel + Copper + Nickel (Ni + Cu + Ni). This coating offers the magnet relatively good protection from corrosion and passive applications. If the magnet will be exposed to moisture or liquid then consider the use of an organic coating such as Epoxy. A hard wearing coating, Epoxy is suited to applications where the magnet will come under some friction or knocking.
Magnets are readily available in Blocks, Discs, Cylinders & Rings. AMF Magnetics specializes in the supply of short-run prototype magnets including Arc Segments, various magnetic orientations etc. If you need a magnet size that we don't carry in stock, submit a Design-a-Magnet enquiry for a quote on your custom magnet design.
Neodymium magnets are offered in several different grades. The first section N30-54 has an operating temperature of up to 80 degrees. Most of our stock only goes up to N38. The second section, denoted with the "M" prefix after the grade has an operating temperature 100 degrees. After this the grades are "H", "SH", "UH" & "EH". In order for the magnet to withstand a higher operating temperature, during production more of the raw material PrNd is incorporated as these elements have a naturally occurring resistance to high temperatures.
