Neodymium Disc Magnet - 15mm x 2mm | N42

Product code: D-D15H2-N42

$2.55for 1 to 9 items
$2.15buy 10 to 99 itemsand save 15%
$1.75buy 100+ itemsand save 31%

Prices are GST Incl.

Volume pricing available on request

Neodymium Disc Magnet - 15mm x 2mm | N42

Product Code D-D15H2-N42
Pull Force* 2.05 kg
Weight 8 gm
Style Neodymium DISC
Gauss 1700
Grade N42
Coating Nickel
Direction of Magnetisation Axially through height
Dimensions Height:2mm, Diameter:15mm
*Measured against up to 10mm mild steel.
Neodymium Disc Magnet - 15mm x 2mm | N42

Magnetic Product Description:

This neodymium magnetic disc has a diameter of 15mm and a height of 2mm. It has a magnetic flux reading of 1700 Gauss and a pull force of 2.05 kilos. It is identified by the AMF magnet part number D-D15H2-N42.


Uses for our rare earth disc magnets:

This Neodymium disc magnet has a thin profile making it ideal for attachment and holding applications. The shallow profile of this circle magnet means it is unlikely to be accidently knocked out of position, holding securely in place. This magnet is a popular choice for electronic devices as the 2mm thickness allows for the magnetic properties to be utilised without the need to accommodate a bulky magnet.

Craftspeople and home users also love the dimensions of this magnet. Perfect for situations that have limited space such as the clearance of a door jam. It is also one of our most highly sought after craft magnets as it provides a strong magnetic hold whilst being thin enough to be disguised in almost any design.



Neodymium Disc Magnet - 15mm x 2mm | N42 (D-D15H2-N42)

Grade
N42 N/A
Max Operating Temperature °C
<=80 N/A
Remanence Br(T)
1.3-1.35 N/A
Remanence Br(kGs)
13-13.5 N/A
Coercivity bHc(kA/m)
>=836 N/A
Coercivity bHc(Oe)
>=10.5 N/A
Intrinsic Coercivity iHc(kA/m)
>=955 N/A
Intrinsic Coercivity iHc(Oe)
>=12 N/A
Max Energy Product(BH)max(KJ/m)
318-350 N/A
Max Energy Product(BH)max(MGOe)
40-44 N/A
Grade N42 N/A
Max Operating Temperature °C <=80 N/A
Remanence Br(T) 1.3-1.35 N/A
Remanence Br(kGs) 13-13.5 N/A
Coercivity bHc(kA/m) >=836 N/A
Coercivity bHc(Oe) >=10.5 N/A
Intrinsic Coercivity iHc(kA/m) >=955 N/A
Intrinsic Coercivity iHc(Oe) >=12 N/A
Max Energy Product(BH)max(KJ/m) 318-350 N/A
Max Energy Product(BH)max(MGOe) 40-44 N/A
Neodymium Disc Magnet - 15mm x 2mm | N42

Magnetic Product Description:

This neodymium magnetic disc has a diameter of 15mm and a height of 2mm. It has a magnetic flux reading of 1700 Gauss and a pull force of 2.05 kilos. It is identified by the AMF magnet part number D-D15H2-N42.


Uses for our rare earth disc magnets:

This Neodymium disc magnet has a thin profile making it ideal for attachment and holding applications. The shallow profile of this circle magnet means it is unlikely to be accidently knocked out of position, holding securely in place. This magnet is a popular choice for electronic devices as the 2mm thickness allows for the magnetic properties to be utilised without the need to accommodate a bulky magnet.

Craftspeople and home users also love the dimensions of this magnet. Perfect for situations that have limited space such as the clearance of a door jam. It is also one of our most highly sought after craft magnets as it provides a strong magnetic hold whilst being thin enough to be disguised in almost any design.



Neodymium Disc Magnet - 15mm x 2mm | N42 (D-D15H2-N42)

Grade
N42 N/A
Max Operating Temperature °C
<=80 N/A
Remanence Br(T)
1.3-1.35 N/A
Remanence Br(kGs)
13-13.5 N/A
Coercivity bHc(kA/m)
>=836 N/A
Coercivity bHc(Oe)
>=10.5 N/A
Intrinsic Coercivity iHc(kA/m)
>=955 N/A
Intrinsic Coercivity iHc(Oe)
>=12 N/A
Max Energy Product(BH)max(KJ/m)
318-350 N/A
Max Energy Product(BH)max(MGOe)
40-44 N/A
Grade N42 N/A
Max Operating Temperature °C <=80 N/A
Remanence Br(T) 1.3-1.35 N/A
Remanence Br(kGs) 13-13.5 N/A
Coercivity bHc(kA/m) >=836 N/A
Coercivity bHc(Oe) >=10.5 N/A
Intrinsic Coercivity iHc(kA/m) >=955 N/A
Intrinsic Coercivity iHc(Oe) >=12 N/A
Max Energy Product(BH)max(KJ/m) 318-350 N/A
Max Energy Product(BH)max(MGOe) 40-44 N/A
